SWITCHED FILTER BANKS

Products > Switched Filter Banks

SWITCHED FILTER BANKS CAPABILITIES

Frequency range: 100 MHz – 20000 MHz

Bandwidths: 0.5% - 150%

Integrated with LC, Cavity, Ceramic, Printed Filter or combination of technologies

Custom designed pin-diode switch technology to meet performance till 20 GHz

Standard GaAs switches for cost effective solutions

Low Profile (< 0.19”)

Improved VSWR and less passband variation

Improved RF shielding/isolation

Improved reliability

NIC's product designs are highly customizable and allow for customers to define package / connector configuration, hermeticity, and application specific compatibility (military, space, etc)

NIC'S SIGNATURE AND LATEST SWITCHED FILTER BANKS

NAME	CHANNELS	FREQ RANGE	BANDWIDTH	PACKAGE CONFIG	PACKAGE DIMENSIONS	FEATURES	DETAILS & DATASHEET
8900 MHz - 16000 MHz 5 Channel Switched Filter Bank	5	Band 1: 9100 MHz Band2: 10600 MHz Band3: 12100 MHz Band 4: 13600 MHz Band 5	Band 1: 240 MHz Band2: 350 MHz Band 3: 350 MHz Band4: 400 MHz Band5: 40	SMA Hermetic	3.60 x 3.10 x 0.56 inches + pins/SMA	Out of band rejection > 90dB	VIEW	REQUEST	SHARE
5000 MHz - 18200 MHz 5 Channel Switched Filter Bank	5	Band 1: 6750 MHz Band2: 9050 MHz Band3: 11300 MHz Band 4: 13750 MHz Band 5:	Band 1: 3500 MHz Band2: 4700 MHz Band 3: 3400 MHz Band4: 2100 MHz Band5:	SMA Hermetic	4.00 x 2.80 x 0.52 inches + pins/SMA	Pin-diode switching	VIEW	REQUEST	SHARE
100 MHz - 3500 MHz 4 Channel Switched Filter Bank	4	Band 1: 400 MHz Band2: 1350 MHz Band3: 2300 MHz Band 4: 3250 MHz	Band 1: 600 MHz Band2: 500 MHz Band3: 1000 MHz Band 4: 1500 MHz	SMA Hermetic	2.00 x 1.50 x 0.33 inches + pins	Excellent Passband Flatness	VIEW	REQUEST	SHARE
10 MHz - 180000 MHz 4 Channel Switched Filter Bank	4	Band 1: 7184 MHz Band2 : 7745 MHz Band3: 2500 MHz HPF Band 4: 8000 MHz LPF	Band 1: 713 MHz Band2: 1470 MHz Band3: N/A Band 4: N/A	SMA Hermetic	1.80 x 1.60 x 0.19 inches + pin/SMA	Wide frequency band, Pin-diode switching, low profile	VIEW	REQUEST	SHARE
1000 MHz - 18000 MHz Thin Film Switched Filter Bank	4	Band 1: 10400 MHz Band2: 5875 MHz Band3: 13425 MHz Band 4: 14800 MHz	Band 1: 2800 MHz Band2: 2250 MHz Band3: 1650 MHz Band 4: 1000 MHz	SMA Hermetic	1.80 x 1.60 x 0.19 inches + pin/SMA	Low Profile (< 0.19 inches). Incorporates thin film filters.	VIEW	REQUEST	SHARE
